Cross Cection (mm²) |
Conductor Construction (n/m) |
Conductor Stranded OD. (mm) |
Cable OD. (mm) |
Conductor Max Resistance AT 20℃ Ω/km |
Current Carring Capacity AT 60℃ (A) |
|
2.5 |
47/0.25 |
1.98 |
4.20×8.60 |
8.21 |
41 |
|
4 |
52/0.3 |
2.35 |
4.60×9.40 |
5.09 |
55 |
|
6 |
78/0.3 |
3.06 |
5.30×10.80 |
3.39 |
70 |
|
10 |
84/0.4 |
3.92 |
8.3×16.9 |
1.95 |
98 |
Technical Data
|
Nominal voltage |
DC: 1.8KV AC: 0.6/1.0KV |
|
Voltage test on completed cable |
AC: 6.5KV，DC: 15KV，5min |
|
Ambient temperature |
-40℃ up to +90℃ |
|
Max. Temperature at conductor |
+120℃ |
|
Service life |
The expected period of use is 25years (Ambient temperature:-40℃ up to +90℃) |
|
Refer to shortcircuit allowable temperature |
The permitted short-circuit temperature is 200℃ referring to a period of 5s. |
|
Bending radius |
≥4×Φ (D<8mm)，≥6×Φ (D≥8mm) |
|
Resistance against acid and alkaline solution |
EN60811-2-1 |
|
Cold bending test |
EN60811-403 |
|
Weathering/UV-resistance |
HD605/A1 |
|
O-zone resistance at complete cable |
EN50396 |
|
Test under fire conditions |
EN 60332-1-2 |
Packing For Shipment
Multiple packaging methods, suitable for different transport conditions.|
Packing Picture |
Packing/Meter |
Pack Reel |
Pallet Dimension(m) |
Pallet/Meter |
|
|
100 Meter/Roll |
/ |
1.12×1.12×1.04m |
4mm²-14400m
6mm²-14000m
|
|
|
200 Meter/Roll |
/ |
1.12×1.12×1.04m |
4mm²-16000m
6mm²-15200m
|
|
|
100 Meter/Reel |
plastic |
1.12×1.12×1.04m |
4mm²-12500m
6mm²-10000m
|
|
|
500 Meter/Reel |
Plywood |
1.12×1.12×1.04m |
4mm²-15000m
6mm²-10000m
|
|
|
1000 Meter/Reel |
Plywood |
1.12×1.12×1.04m |
4mm²-15000m
6mm²-12000m
|
|
|
3000 Meter/Reel |
Plywood |
1.12×1.12×1.04m |
4mm²-15000m
6mm²-12000m
|
