Cross Cection
（mm2）
|
Conductor Construction
(n/mm)
|
Conductor Stranded OD.（mm）
|
Cable OD.（mm）
|
Tinned copper)
Conductor Max.Resistance AT 20℃（Ω/km）
|
Current Carring Capacity AT 60℃（A）
|
|
1.5 |
30/0.25 |
1.58 |
4.60 |
13.7 |
30 |
|
2.5 |
47/0.25 |
1.98 |
5.10 |
8.21 |
41 |
|
4 |
52/0.3 |
2.35 |
5.50 |
5.09 |
55 |
|
6 |
78/0.3 |
3.06 |
6.30 |
3.39 |
70 |
|
10 |
84/0.4 |
4.60 |
7.80 |
1.95 |
98 |
|
16 |
128/0.4 |
5.60 |
9.20 |
1.24 |
132 |
|
25 |
196/0.4 |
6.95 |
11.30 |
0.795 |
176 |
|
35 |
276/0.4 |
8.30 |
13.30 |
0.565 |
218 |
The current-carrying capacity is under the situation of laying the single cable in air.
|
Nominal voltage |
DC: 1.5KV AC: 1.0/1.0KV |
|
Voltage test on completed cable |
AC: 6.5KV DC: 15KV, 5min |
|
Ambient temperature |
Max. ambient temperature: 90℃ |
|
Thermal endurance properties |
120℃, 20000h, elongation at break≥50% |
|
Refer to short circuit allows the temperature |
The permitted short-circuit-temperayure is 250℃ referring to a period of 5s |
|
Smoke emission of complete cable |
EN61034-2 |
|
Test under fire conditions |
EN60332-1-2 |
|
Dynamic penetration test |
EN50618 |
|
Resistance against acid and alkaline solution |
EN60811-404 |
|
Cold bending test |
EN60811-504 |
|
Weathering/UV-resistance |
EN50618 |
|
Assessment of halogen |
EN50525-1 |
Technical Data
Packing For Shipment
|
Packing Picture |
Packing/Meter |
Pack Reel |
Pallet Dimension(m) |
Pallet/Meter |
|
|
100 Meter/Roll |
/ |
1.12×1.12×1.04m |
4mm²-14400m
6mm²-14000m
|
|
|
200 Meter/Roll |
/ |
1.12×1.12×1.04m |
4mm²-16000m
6mm²-15200m
|
|
|
100 Meter/Reel |
Plastic |
1.12×1.12×1.04m |
4mm²-12500m
6mm²-10000m
|
|
|
500 Meter/Reel |
Plywood |
1.12×1.12×1.04m |
4mm²-15000m
6mm²-10000m
|
|
|
1000 Meter/Reel |
Plywood |
1.12×1.12×1.04m |
4mm²-15000m
6mm²-12000m
|
|
|
3000 Meter/Reel |
Plywood |
1.12×1.12×1.04m |
4mm²-15000m
6mm²-12000m
|
Multiple packaging methods, suitable for different transport conditions.
